Corvision Plus Aluminium Sliding Door Systems
Supersize your glass door options with Corvision Plus, suitable for sash dimensions up to a massive 4m width or height. This minimalist system has visible profile sections of just 25mm which allows coverage of huge openings with a glass surface of 94% and still maintains outstanding thermal and acoustic performance.
- Minimalist sliding system specially suitable for large dimensions (up to 4,000 mm/sash of width or height)
- Possible to cover great openings with a glass surface of 94%
- Visible section of just 25 mm
- Outstanding thermal and acoustic performance
- It comes with the possibility of motorised opening for sashes up to 700 kg, and manual opening for up to 400 kg. Additionally, it allows to place multipoint lock systems by operating rod, with or without key
- The rollers are placed in the frame, and the sashes count with a stainless steel reinforced rolling area which makes the sliding movement smoothe
- Possibility of corner sash encounters at 90º without needing a mullion
- The motorised version allows to completely hide the sash within the frame in closing position
Technical Information
Specification & Downloads
System Options
- Sliding of 2, 4 or 6 sashes
- Up to 4 rail configurations
- 1 sash + 1 fixed / 2 sashes + 1 fixed
- Possibility of corner sash encounters at 90º without mullions
- Pocket solution possibility 1,2,3, and 4 sashes
Finishes
- Possibility of dual colour systems
- Colour powder coating (RAL, mottled and rough)
- Wood effect powder coating
- Anti-bacterial powder coating
- Anodised
Sections
- Frame – 180 mm – 278 mm 3 rails
- Sash – 69 mm
Polyamide Strip Length
- 18 / 40 mm
Profile Thickness
- Door 2.0mm
Glazing
- Max 56mm
Maximum Sash Dimensions
- Width (L) 4000mm, Height (H) 4000mm – Glass surface ≤ 14 m²
Maximum Sash Weight
- 400 kg Manual, 750 kg motorised
- Consult maximum weight and dimensions according to typologies
